DSX2 LED Area Luminaire

DSX2 LED Area Luminaire

SKU: 191848734254

The D-Series distills the benefits of the latest in LED technology into a high performance, high efficacy, long-life luminaire. The outstanding photometric performance results in sites with excellent uniformity, greater pole spacing and lower power density. The Size 2 is ideal for replacing 400-1000W metal halide in area lighting applications with energy savings of up to 80% and expected service life of over 100,000 hours.


    • 400-1000W MH Replacement
    • Lumen packages from 10,000 - 51,800 delivered lumens up to L92/50,000 hours
    • Efficacies up to 143 lumens per watt
    • 11 factory-rotatable distributions available
    • Available in 3000K, 4000K & 5000K CCT and Amber LED
    • Best-in-class Category C surge protection
    • Weight: 36 lbs; EPA: 2.0 ft2

    • NLTAIR2: nLight AIR generation 2 enabled
    • PIRHN: Network, Bi-Level motion/ambient sensor
    • PER: NEMA twist-lock receptacle only (no controls)
    • PER5: Five-wire receptacle only (no controls)
    • PER7: Seven-wire receptacle only (no controls)
    • DMG: 0-10V dimming extend out back of housing for external control (no controls)
    • DS: Dual switching
    • PIRH: Bi-level, motion/ambient sensor, 15-30’ mountingheight, ambient sensor enable at 5fc
    • PIRH1FC3V: High/low, motion/ambient sensor, 8-15’ mountingheight, ambient sensor enabled at 1fc
    • FAO: Field Adjustable Output
